2D arsenenes

Yi Hu; Junchuan Liang; Lixiu Zhang; Zhong Jin; Liming Ding

doi:10.1088/1674-4926/43/3/030201

J. Semicond. > 2022, Volume 43?>?Issue 3?> 030201

RESEARCH HIGHLIGHTS

2D arsenenes

Yi Hu^{1, 2}, Junchuan Liang^{1, 2}, Lixiu Zhang³, Zhong Jin^{1, 2,} and Liming Ding^3,

+ Author Affiliations

1. Key Laboratory of Mesoscopic Chemistry (MOE), School of Chemistry and Chemical Engineering, Nanjing University, Nanjing 210023, China
2. Shenzhen Research Institute of Nanjing University, Shenzhen 518063, China
3. Center for Excellence in Nanoscience (CAS), Key Laboratory of Nanosystem and Hierarchical Fabrication (CAS), National Center for Nanoscience and Technology, Beijing 100190, China

Author Bio:

Yi Hu received his BS in Chemistry from Sichuan University in 2014. He got his PhD under the supervision of Prof. Zhong Jin in School of Chemistry and Chemical Engineering at Nanjing University. His research focuses on 2D nanomaterials and related devices.

Junchuan Liang received his BS in Lanzhou University in 2019. He is now pursuing his PhD under the supervision of Prof. Zhong Jin in School of Chemistry and Chemical Engineering at Nanjing University. His research focuses on 2D nanomaterials.

Lixiu Zhang got her BS degree from Soochow University in 2019. Now she is a PhD student at University of Chinese Academy of Sciences under the supervision of Prof. Liming Ding. Her research focuses on perovskite solar cells.

Zhong Jin received his BS (2003) and PhD (2008) at Peking University. He worked as a postdoc at Rice University (2008–2010) and Massachusetts Institute of Technology (2010–2014). At 2014, he was appointed as a professor in School of Chemistry and Chemical Engineering at Nanjing University. His research focuses on the development of advanced materials and devices for clean energy conversion and storage.

Liming Ding got his PhD from University of Science and Technology of China (was a joint student at Changchun Institute of Applied Chemistry, CAS). He started his research on OSCs and PLEDs in Olle Ingan?s Lab in 1998. Later on, he worked at National Center for Polymer Research, Wright-Patterson Air Force Base and Argonne National Lab (USA). He joined Konarka as a Senior Scientist in 2008. In 2010, he joined National Center for Nanoscience and Technology as a full professor. His research focuses on innovative materials and devices. He is RSC Fellow, the nominator for Xplorer Prize, and the Associate Editor for Journal of Semiconductors.

Corresponding author: Zhong Jin, zhongjin@nju.edu.cn; Liming Ding, ding@nanoctr.cn
