Abstract: This letter proposes a novel IGBT structure with an n-type barrier(NB-IGBT) formed on the silicon surface to enhance the conductivity modulation effect with a relatively simple fabrication process. TCAD simulation indicates that the NB-IGBT offers a current density 49% higher and turn-off losses 25% lower than a conventional field-stop IGBT(FS-IGBT) with a similar breakdown voltage, turn-off time and avalanche energy. Furthermore, the NB-IGBT exhibits extremely large transconductance, which is favorable to turn-on and turn-off. Therefore, the proposed IGBT offers an attractive option for high-voltage and large-power electronics applications.

Key words: breakdown voltage, conductivity modulation, current density, latch up, IGBT



[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
Fig1.  (a) Proposed and (b) conventional FS-IGBT structures.

Fig2.  (Color online) Avalanche $I$--$V$ characteristics of the proposed IGBT with the n-type barrier region. The simulation result of conventional FS-IGBT with the same cell dimensions is included for comparison.

Fig3.  Potential distribution along the vertical direction between the emitter metal,the n+source,the p-base,and part of the n-drift region under the avalanche conditions.

Fig4.  Forward $I$--$V$ characteristics of the proposed IGBT with the n-type barrier region. The simulation result of conventional FS-IGBT with the same cell dimensions is included for comparison.

Fig5.  Excess carrier distribution along the vertical direction of the proposed IGBT with the n-type barrier region. The simulation result of conventional FS-IGBT with the same cell dimensions is included for comparison.

Fig6.  Potential distribution along the vertical direction between the emitter metal,the n+source,the p-base,and part of the n-drift region at collector current of 150 A/cm$^2$. The simulation result of conventional FS-IGBT with the same cell dimensions is included for comparison.

Fig7.  Transfer characteristics of the proposed IGBT with the n-type barrier region at a collector voltage of 1.64 V. The simulation result of conventional FS-IGBT with the same cell dimensions is included for comparison.

Fig8.  Saturation current waveforms of the proposed IGBT with the n-type barrier region at gate voltage of 15 V. The simulation result of conventional FS-IGBT with the same cell dimensions is included for comparison.

Fig9.  Turn-off test circuit,the DC bus voltage is set at 600 V,the gate voltage is set at $\pm$15 V,the load current density at 150 A/cm$^2$ and the stray inductance at 60 nH and the gate resistor at 5 Ω.

Fig10.  (Color online) Turn-off waveforms of the proposed IGBT and FS-IGBT at current density of 150 A/cm$^2$,bus voltage of 600 V,gate resistor of 5 Ω and stray inductance of 60 nH.

Fig11.  (Color online) Unclamped inductive switching waveforms of the proposed IGBT and FS-IGBT at current density of 150 A/cm$^2$,bus voltage of 600 V,gate resistor of 5 $\upOmega $ and the maximum load inductance of 0.3 mH.

Fig12.  Turn-off losses characteristics of the proposed IGBT and FS-IGBT by varying p+collector concentration at current density of 150 A/cm$^2$,bus voltage of 600 V,gate resistor of 5 Ω and stray inductance of 60 nH.
